50&80 Single Head Chamfering Machine

50&80 Single Head Chamfering Machine
Product Details:

Feature:

Single Head Chamfering Machine



1.    Semi-automatic precise chamfering machine, manual feeding, automatic clamping and automatic driving and reversing machine.

2.    The clamp mould and cutter head are exquisitely designed to ensure the center line of processed object and cutter head will not be changed.

3.    The processing of outer angle and inner angle at tube end and the end surface can be finished uniformly in one time.

4.    The speed can be changed by changing the belt pulley to adapt to different metal material and ensure the longest service life of cutter.


50DT Single Head Chamfering Machine







Item
Model
50DT
1
Process Diameter
Round Pipe
Φ9-Φ52mm
Round Rod
Φ9-52mm
2
Air Pressure
0.4-0.6 Mpa
3
Cutter Head
Standard cutter head application range is Φ15-50mm
4
Main Motor Power
0.75 KW
5
Standard Accessories
1.    One piece standard cutter head
2.    One group clamp mould
6
Machine Dimension
570x750x1000mm
7
Machine Weight
120KG





80DT Single Head Chamfering Machine



Item
Model
80DT
1
Process Diameter
Round Pipe
Φ20-Φ80mm
Round Rod
Φ9-50mm
2
Air Pressure
0.4-0.6 Mpa
3
Cutter Head
Standard cutter head application range is Φ20-80mm
4
Main Motor Power
1.5 KW
5
Standard Accessories
1.    One piece standard cutter head
2.    One group clamp mould
6
Machine Dimension
800x750x1350mm
7
Machine Weight
380KG
